2016 Zero FXS

Editor Score: 85.0%
Engine 18.5/20
Suspension/Handling 12.0/15
Transmission/Clutch 10.0/10
Brakes 8.0/10
Instruments/Controls5.0/5
Ergonomics/Comfort 8.5/10
Appearance/Quality 8.5/10
Desirability 8.0/10
Value 6.5/10
Overall Score85/100

If you’ve been keeping tabs, we’ve ridden the Zero FX quite a lot. First in 2013 when I rode one to the top of Pikes Peak, during the 91st running of the iconic event. Later that year I was fortunate enough to be drafted onto a team that raced another FX twice around the clock, making history as the first electric motorcycle to do so. In 2014, Zero’s VP of Global Marketing, and off-road racing legend, Scot Harden, invited E-i-C Kevin Duke and myself to his backyard track to get a taste of the FX in its natural (dirt) environment. Following that, Editor Roderick and I took another FX to Adams Motorsports Park to put it head-to-head with a Suzuki DRZ-400SM, for a gas vs. electric supermoto face-off – where it won! And, because I hadn’t had enough of the FX, in early 2015, I had the bright idea to take one to the short track at Del Mar to try my hand at flat track “racing” (in quotes because I had no idea what I was doing). So, with no less than five Zero FX stories in our archives, a natural next question might be: “Another Zero FX review?!”

Yes indeed, and here’s why: save for the trip to Harden’s compound and the trek to Del Mar to play in the dirt, each time we rode the FX on pavement the bike had been modified for supermoto use by Harlan Flagg of Hollywood Electrics. The most obvious change being the switch to 17-inch wire-spoke wheels and sticky rubber to replace the 21-inch front and 18-inch rear that comes standard. At around $3,000, Flagg’s top-of-the-line SuMo kit for the FX transforms the bike into an immensely entertaining kart track or backroad bomber, but it’s a hefty price to pay on top of the $10,990 for the bike itself ($9,890 after a $1,100 federal tax credit).

Fitting 17-inch wheels and sticky Pirelli rubber on an FX chassis to create the 2016 Zero FXS is an idea we’re surprised Zero didn’t come up with long ago.

Fitting 17-inch wheels and sticky Pirelli rubber on an FX chassis to create the 2016 Zero FXS is an idea we’re surprised Zero didn’t come up with long ago.

Give ’em What They Want

For 2016, Zero dug into its own parts bin of 17-inch wheels from the S and SR models to offer the FX in supermoto trim direct from the factory. The result is the 2016 Zero FXS. In addition to the wheels, 110/70-17 front and 140/70-17 rear Pirelli Diablo Rosso II tires are also fitted, the same rubber used on the SR. The S platform also donates its bigger brakes to the FXS, the 320mm disc replacing the 240mm disc on the FX. A J. Juan twin-piston caliper bites down on the disc, supported by steel-braided lines and switchable Bosch ABS.

Zero’s partnership with Showa sees a 41mm fork working in conjunction with a single shock. Both units are fully adjustable, but damping is adjusted slightly from the units on the FX to better suit road duties. Front suspension travel is 7.0 in., rear 8.94 in.

Zero’s TJ Aguirre in the process of removing the retaining bar for the swappable batteries. The premise for the removable batteries was inspired by Zero’s military contracts, which stipulated that the motorcycle had to be able to go from zero to full charge in 60 seconds or less. There was no way Zero’s existing batteries and charging systems could achieve this, so the solution was to simply make the batteries removable and replaceable.

Zero’s TJ Aguirre in the process of removing the retaining bar for the swappable batteries. The premise for the removable batteries was inspired by Zero’s military contracts, which stipulated that the motorcycle had to be able to go from zero to full charge in 60 seconds or less. There was no way Zero’s existing batteries and charging systems could achieve this, so the solution was to simply make the batteries removable and replaceable.

As for the electrics, both the FX and FXS see a 14% increase in capacity from their hot-swappable batteries, the single battery rated at 3.3kWh and the dual-battery setup 6.5kWh (2.9kWh and 5.7kWh nominal, respectively). Zero’s new Z-Force Interior Permanent Magnet (IPM) motor is equipped on FXS models, its ability to create less heat and to more efficiently dissipate heat is a big benefit to supermoto riders (read the Zero DSR review here for more details on the IPM motor, or grab some popcorn and watch this video of Zero’s Director of Powertrain Engineering, Ryan Biffard, give an in-depth explanation of his patent-pending creation).

Meanwhile, the FX (no S) will retain the Surface Mount Permanent Magnet (SMPM) motor used previously. Power output doesn’t change regardless of the motor, meaning 70 lb-ft of torque is on tap, as well as 44 hp (27 hp with the single ZF3.3 battery). Combined with a claimed curb weight of 293 lbs., the FXS has all the ingredients to upset sportbike riders in the canyons.

Let’s Get Crackin’

The world famous Alice’s Restaurant would be the start/finish point for our ride aboard the FXS. If you’ve never been to this popular moto-hangout, it’s nestled deep in the woods of Northern California, which means it’s surrounded by wonderfully twisty ribbons of pavement in all directions. Zero devised a guided loop for the assembled journos to ride, with a pace that left nobody wishing for more. Overnight rains in the area meant the roads were less than ideal, and Zero personnel warned us repeatedly to be mindful of throttle application, as sport tires, damp roads and 70 lb-ft of torque were a potential recipe for a highside.

Roads like this are what the FXS lives for.

Roads like this are what the FXS lives for.

My plan of attack was to ride like I would on any other canyon ride, with no concessions to battery savings. The FXS stayed in Sport mode to take advantage of full power. The reasoning was twofold: First, I wanted to test the bike’s range in a setting that would drain the battery quickly. The second reason is inspired by the experience Roderick and I had during our Gas vs. Electric comparison, where the FX would provide two thrilling laps before thermal cutback diluted the fun significantly. Basically, I wanted to try and overheat the new IPM motor to see how it would react.

From the start, I was liberal with my e-throttle application, careful not to spin up the rear tire, but also demanding as much juice as possible. It’s said over and over again, but the sheer acceleration of electrics is intoxicating, and the FXS is no exception. Power delivery didn’t seem as instant as I remember on past FX models, but without having one to test side-by-side it was impossible to know. Zero says the software hasn’t changed. Still, acceleration is fierce, and if you time it right, goosing the throttle can point the front towards the sky.

The FXS shares its brakes with its S and DS cousins that weigh over 100 lbs. more. On the FXS, that translates into being able to brake late with just one finger.

The FXS shares its brakes with its S and DS cousins that weigh over 100 lbs. more. On the FXS, that translates into being able to brake late with just one finger.

The FXS’s slim body, light weight and wide bars make for a motorcycle eager to be tossed into turns, though the wet roads meant exploring the edge grip of the Pirelli tires would have to wait until another time. That said, the Diablo Rosso II rubber allowed for respectable lean angles considering the conditions.

As with the DSR, some of the assembled journos weren’t happy with the ABS, claiming it intervened too soon and got especially confused while braking over bumps. I personally was never able to activate the front ABS, except while squeezing the lever over rough patches of road. Depending on your riding style, applying the brakes earlier but with less force could be the answer. Either that or switching off the ABS entirely.

Wide bars and relatively little weight make the FXS easy to manhandle through turns.

Wide bars and relatively little weight make the FXS easy to manhandle through turns.

From a performance standpoint, the FXS lives up to the hype of being a supremely fun and entertaining canyon carver. On tight roads I have no doubt it could hang with nearly anything out there. As always, one of the issues with electrics centers around range. Our test loop was exactly 37 miles, according to the tripmeter on my FXS. Granted, it was a brutal 37 miles from a battery life standpoint, but after a thorough flogging, the battery percentage indicator on the dash read 13% charge remaining, with acceleration getting noticeably weaker beginning at 20% charge remaining in order to conserve battery life. Considering Zero claims 52 miles of range in combined city/highway use (“highway” meaning sustained speeds of roughly 70 mph), still having 13% charge left after nearly 40 hard miles is respectable.

Looking at the bigger picture, riding the FXS to the canyons, making a few runs, then heading home seems nearly impossible unless your backyard literally is in the canyon or you take a long lunch break to recharge. And you’ll have to plug into your standard wall outlet, as, unlike the S, SR, DS and DSR, the FXS isn’t compatible with the Zero Charge Tank, meaning it isn’t compatible with J1772 charge plugs at level 2 stations.

Ergonomically, the FXS’s MX roots are obvious with its narrow seat, slim waistline and upright bars.

Ergonomically, the FXS’s MX roots are obvious with its narrow seat, slim waistline and upright bars.

As for the motor overheating, despite my best efforts, I wasn’t able to reach the IPM motor’s thermal limits on this ride. Taking into account the chilly ambient temps (55ºF) and periods where we were stuck behind slow-moving traffic, a more thorough test will have to come later when we can stick the FXS on a track.

Better Late Than Never

As far as fun quotients go, the FXS on a tight road is a small slice of heaven. It’s so easy to toss around and, as we experienced during our Gas vs. Electric comparison, it can leave its internal combustion counterparts in the dust with a twist of the throttle.

You’d never be able to ride your internal combustion trail bike on a city park walking trail without pissing off pedestrians. With the FXS, park walkers hardly give you a second look.

You’d never be able to ride your internal combustion trail bike on a city park walking trail without pissing off pedestrians. With the FXS, park walkers hardly give you a second look.

Limited range, long charge times, and relatively high costs are an inherent downside to electrics and the FX is no exception. Sure you can spring for extra FX batteries at $2,852 a pop, or supplemental $599.99 Quick Chargers, but neither option is cost effective or convenient. A federal tax credit of $1,100 helps bring the overall cost of the FXS down to $9,890, with further incentives available in select states. Ultimately, it’s up to you to decide whether the FXS is worth it. If a thrill ride is what you’re after and the above limitations don’t deter you, then the 2016 Zero FXS is worth a look.

Zero FXS
+ Highs

  • Thrilling acceleration
  • Toss-anywhere handling
  • A factory, street-legal supermoto from someone other than Suzuki
– Sighs

  • Limited range
  • Long charge times
  • Still expensive despite federal credit
