2016 Yamaha YZ450FX

Editor Score: 96.0%
Engine 19.5/20
Suspension/Handling 15.0/15
Transmission/Clutch 10/10
Brakes 8.0/10
Instruments/Controls5.0/5
Ergonomics/Comfort 10/10
Appearance/Quality 10/10
Desirability 9.5/10
Value 9.0/10
Overall Score96/100

In its 60-year history Yamaha’s line-up has never boasted more motocross and off-road competition models than right now.

Already fortified with a broad range of two-stroke models, including the stalwart YZ85, YZ125 and YZ250s (Yamaha is the only Japanese manufacturer to maintain a full range of motocross ring dings), the tuning fork brand just recently unleashed its tasty new YZ250X for two-stroke off-road customers. In the four-stroke segment, the YZ250F and YZ450F motocross machines already run at the head of their respective classes, and Yamaha upped its game last year by unleashing two new off-road thumpers, the WR250F and YZ250FX, to satisfy customer needs ranging from casual trail riding and enduros to full-blown cross-country competition.

All that was left was to revamp the WR450F to incorporate the rearward inclined engine configuration of the YZ450F in similar fashion to the 250s, but Yamaha has once again gone a step further by also introducing the all-new YZ450FX. That gives Yamaha fans their choice of no less than seven off-road competition models from a single Japanese manufacturer.

If you didn’t know what you were looking at, you might think that the YZ450FX is just another Yamaha motocrosser. However, such items as the heavy-duty plastic skidplate and the sharkfin-shaped rear disc protector are visual clues to the FX’s off-road racing intentions.

If you didn’t know what you were looking at, you might think that the YZ450FX is just another Yamaha motocrosser. However, such items as the heavy-duty plastic skidplate and the sharkfin-shaped rear disc protector are visual clues to the FX’s off-road racing intentions.

After the fun we had sampling the 2015 YZ250FX, which went on to become the strongest seller in the 250cc off-road competition segment last year, you can bet we were thrilled to receive an invitation to ride the new YZ450FX at Southern California’s Cahuilla Creek Motocross Park near San Diego. The facility’s sprawling layout offers not only a full motocross track, it also features plenty of single-track trails and boulder-infested terrain to allow proper vetting of the 450FX’s off-road capabilities. And after spending a few hours on the bike, we can state in full confidence that Yamaha has another potential hit on its hands. The YZ450FX isn’t some watered-down motocross machine detuned for off-road use. It harnesses the mighty power and quick handling of the YZ450F in a machine specifically tailored to win at the highest levels of off-road competition.

Steeper first, second and third gear ratios and off-road-specific ECU conspire to turn the YZ450FX into a mountain goat on steroids. Its low-end tractability and smooth yet brawny power output can make short work of technical obstacles like this rock. Test rider Nic Garvin goes for the proverbial “leap in a single bound.”

Steeper first, second and third gear ratios and off-road-specific ECU conspire to turn the YZ450FX into a mountain goat on steroids. Its low-end tractability and smooth yet brawny power output can make short work of technical obstacles like this rock. Test rider Nic Garvin goes for the proverbial “leap in a single bound.”

To prove its mettle, we enlisted Southern California off-road privateer Nic Garvin, who contests the Pro class in the Kenda SRT/AMA National Championship Hare & Hound Series aboard a KTM, to hammer the FX and give us his thoughts. After taking a few loops of Yamaha’s nicely executed Cahuilla off-road loop, Garvin was impressed.

“Honestly, I was skeptical that it could be a great off-road bike when I first looked it over because it was missing some things that you would expect on a stock off-road bike,” Garvin said. “It has a skid plate, the shark fin to protect the rear brake disc and the 18-inch rear wheel, but it was missing other obvious things like handguards and a larger fuel tank [the stock FX tank holds 2.0-gallons of fuel, same as the YZ450F]. But when I rode it I was impressed with how aggressive the power is while still being smooth and controllable. Right off the bottom it has a lot of torque, which makes it easy to ride. All you have to do is grab a handful of throttle, and it just rips. The midrange power is really smooth, and it has plenty of top-end. Before you know it, you’re really moving.”

The YZ450FX’s fuel-injected, DOHC, 449cc engine shares many of the same engine specs as the F, but the FX is fitted with electric start, a different ECU and a different crankshaft and counterbalancer than the motocross bike. The clutch and transmission are also redesigned for cross-country use.

The YZ450FX’s fuel-injected, DOHC, 449cc engine shares many of the same engine specs as the F, but the FX is fitted with electric start, a different ECU and a different crankshaft and counterbalancer than the motocross bike. The clutch and transmission are also redesigned for cross-country use.

Of course, Yamaha started with its World Motocross Championship-winning YZ450F, which incorporates the YZ’s mass-centralizing, rearward slanted, liquid-cooled, fuel-injected, DOHC, titanium-valved, 449cc four-stroke Single. The FX’s 97.0mm x 60.8mm bore and stroke are identical to the YZ450F, as are its 12.5:1 compression ratio and Yamaha Fuel Injection (YFI) system, which utilizes a Keihin 44mm throttle body. The FX’s double overhead cams even use the same lift and duration specs as the YZ’s. The only difference is a slight relocation of the decompression mechanism.

That said, there are significant differences that set the two models apart. First and foremost is the FX’s convenient electric start system (a kickstarter is still employed as a backup). The two models still use the same engine cases – look at the front of any ’16 YZ450 engine, under the exhaust port, and you will see the mounting bosses for the FX’s electric starter. The only real visible difference is that the FX’s ignition cover is slightly wider to accommodate the heavy-duty, 160-Watt generator assembly that keeps the FX’s battery charged and also allows for the addition of accessory lighting.

Despite its engine and transmission changes, we were impressed with just how competent the FX was on the motocross track portions of our Cahuilla Creek test loop, especially after we reprogrammed the ECU. The FX can shred berms with the best 450cc motocrossers in the class.

Despite its engine and transmission changes, we were impressed with just how competent the FX was on the motocross track portions of our Cahuilla Creek test loop, especially after we reprogrammed the ECU. The FX can shred berms with the best 450cc motocrossers in the class.

The FX’s ECU is also different than the YZs, and the two ECUs are not interchangeable. The FX’s unit is tuned to deliver a different style of power to meet the needs of cross country racing as opposed to motocross, and it also features additional leads to run the electrical system. Like the YZ’s ECU, it can, however, be tuned to alter the engine’s power delivery via Yamaha’s handy accessory GYTR Power Tuner. It should also be noted that the FX’s ECU is also sold by Yamaha as an accessory for WR riders who want it, although the swap surrenders the WR’s Green Sticker-compliant status.

121615-2016-yamaha-YZ450FX-AlternateECU-Settings

After a few more loops aboard the bike with the stock ECU settings, we went ahead and had Yamaha factory test rider Travis Preston retune the bike with the GYTR Power Tuner (see table above) before sending Garvin back out on the trail. These are not the same settings Preston uses when dialing-up the YZ450F’s power curve because the base settings differ between the FX and the motocrosser. That said, Preston’s personal FX settings work equally well, and they make a noticeable difference in the engine performance. Garvin returned even more pleased with the FX’s power delivery.

2016 Yamaha YZ450F Review

“If I was going to race this bike, I would insist on making the ECU changes,” he said. “It is already very good in stock form, but going in and changing a few settings with the power tuner really makes the engine come alive. The changes give it a lot more snap everywhere. It’s a lot more responsive and aggressive, yet it doesn’t lose any of its smoothness throughout the rev range.”

The YZ450FX’s five-speed transmission features steeper first, second and third gears for low-speed trail work and a taller fifth gear for engaging the warp factor in open terrain.

The YZ450FX’s five-speed transmission features steeper first, second and third gears for low-speed trail work and a taller fifth gear for engaging the warp factor in open terrain.

There are differences to the FX’s internals as well, the biggest of these being a wide-ratio five-speed transmission that incorporates steeper first, second and third gear ratios for crawling through technical sections and a taller fifth gear ratio for high-speed riding across open terrain. Yamaha says that the gearing is 30% wider than the YZs. The FX’s 13/50 final drive gearing is only two teeth steeper than its motocross sister, but the variance in first gear alone is the equivalent of adding 13 teeth to the YZ’s rear sprocket while fifth gear’s “overdrive” is the equivalent of taking four teeth off the YZ. Even though the FX’s transmission ratios aren’t as close as the YZs, Garvin was impressed with just how much pull each gear offered – at least from second gear on up to fifth.

“First gear isn’t something that I would find myself needing to use for desert work because it is so short, but I could see it in GNCC racing,” Garvin said. “Even in tight stuff, I was impressed with how much range I had with second gear, and if I was just out trail riding, I would probably leave the bike in third gear most of the time. The engine is such a tractor, and it just pulls third gear really well even on tight single-track trails. Fifth gear definitely makes this bike go fast! It would be great for the desert. Fourth is already fast, but this gear is just over the top. The funny thing is, I think that the FX can be really versatile. If you hadn’t told me that this isn’t a motocross bike, I would be totally happy taking it out on the track and racing motocross with it.”

The FX’s cable-operated clutch is designed to offer lighter actuation and easier slippage when picking through tight, technical or slimy off-road sections.

The FX’s cable-operated clutch is designed to offer lighter actuation and easier slippage when picking through tight, technical or slimy off-road sections.

The FX’s cable-actuated clutch (no hydraulics here) is also significantly changed to meet the needs of off-road racing versus motocross. Its clutch pack utilizes different plates designed to better withstand abuse from slipping the clutch, such as when the rider is forced to paddle up a tight and/or slippery uphill section. Lighter clutch springs, a 5mm shorter actuator arm and an added bushing are also used to make the FX’s clutch action lighter, smoother and give it a wider range of play in the friction zone. Yamaha also added a judder spring to the FX clutch hub for better shock resistance for instances when the rear wheel catches a big rock or root.

Garvin offered high praise for the clutch’s feel, although he did note, “I’m used to a hydraulic clutch, so I did have to use the adjuster on the clutch perch to keep the action where I wanted it.”

Other subtle but no less substantial differences include a lighter crankshaft to offset the additional reciprocating weight of the FX’s larger ignition rotor. It’s also balanced differently than the YZ’s crank, delivering a 100% balance factor compared to the YZ’s 88% balance factor. “Balance factor” refers to the percentage of crankshaft weight placed opposite of the crank pin to counteract the acceleration and deceleration forces of the piston and connecting rod. Yamaha claims that the FX’s crank-balance factor translates into less engine vibration.

Some of the YZ’s handling traits stunt the FX in the handling department. Its steering is light but not as precise as we’d like at slow speeds, and the front end is slightly nervous at high speeds.

Some of the YZ’s handling traits stunt the FX in the handling department. Its steering is light but not as precise as we’d like at slow speeds, and the front end is slightly nervous at high speeds.

The FX chassis geometry is identical to the YZ’s, but Yamaha has tuned the chassis flex for off-road use by swapping to engine mounting brackets that are 2mm thinner than the 8mm units found on the YZ. They’re also shaped differently. Yamaha already tweaked the 2016 YZ450F’s chassis for better bump compliance by adjusting the fork offset to deliver more front-end feel and better turning stability and switching to frame spars that are 12mm wider at the swingarm pivot; the YZ450FX incorporates these changes as well.

For flat out off-road use, the FX chassis generally delivers very good handling, although its moto roots are evident. Its steering is light, but Garvin noticed that he had to work at tight switchbacks, and through technical rocky sections at low speeds because of what he calls a “top-heavy” feel. At higher speeds, he also noticed the front end was a tad nervous.

“There are other stock off-road bikes that are more stable at high speeds” Garvin said. “If this was my bike, I would spend a lot more time dialing in the suspension settings to see if I could eliminate the twitch completely, but if I couldn’t, I would just put a steering damper on it, like a Scott’s or a GPX, and it would be fine. Overall, though, it handles well. It carves sand turns well, although sometimes the front end will ‘knife’ in flat turns. It also tracks well through rutted corners – it doesn’t want to dart right or left.”

Suspension at both ends is plush, with KYB’s 48mm Speed Sensitive System (SSS) fork up front and a fully adjustable piggyback reservoir fork out back. We love the fork, but aggressive or heavy riders might opt to revalve the shock for better bottoming resistance.

Suspension at both ends is plush, with KYB’s 48mm Speed Sensitive System (SSS) fork up front and a fully adjustable piggyback reservoir fork out back. We love the fork, but aggressive or heavy riders might opt to revalve the shock for better bottoming resistance.

The YZ450FX carries the latest generation 48mm KYB Speed Sensitive System (SSS) fork, which uses coil springs and dampers in both legs, instead of air, and is fully adjustable for compression and rebound damping. Out back is a KYB piggyback shock that offers preload, high- and low-speed compression damping, and rebound damping adjustability. Both ends differ from the YZ450F in that their valving is softer for off-road use. The fork spring rate is reduced from the motocross bike’s 5.0 N/mm to 4.5 N/mm, while the shock spring rate is the same 56 N/mm as the YZ450F, which saw its shock spring rate reduced from 58 N/mm for the 2016 model year.

Out on the trail, Garvin noted that the front and rear suspension are more than competent, although he did have Yamaha’s techs back off two clicks on the fork compression and add two clicks of low-speed compression to the shock to balance the bike for his tastes. Both ends deliver smooth and controllable travel for off-road use, although Garvin hinted that most pro riders might like the valving to be just a bit more aggressive than the stock suspension delivers. He had no complaints with the spring rates.

“The stock suspension on this bike is really plush, and the forks are really nice, but if you bottom the rear end over a dropoff or in deep braking bumps, it really clanks.”

Braking is superb on the 450FX, with the 270mm front and 245mm rear discs delivering excellent feel and plenty of power for crawling up or down any obstacle.

Braking is superb on the 450FX, with the 270mm front and 245mm rear discs delivering excellent feel and plenty of power for crawling up or down any obstacle.

The FX’s brakes are identical to the YZ’s. The 270mm front disc and Nissin two-piston caliper delivers strong and linear stopping power, and the same goes for the 245mm rear disc and single-piston caliper out back. Garvin said he is a fan of Yamaha’s brakes.

“They stay strong and smooth without fading or getting grabby – I wasn’t able to get them to overheat,” he said. “That’s exactly what you want on an off-road bike. The front brake is really, really good.”

Ergonomically speaking, the Yamaha is as narrow as a rail, offering a slim, flat seat and narrow radiator shrouds that allow the rider to easily shift his or her seating position as needed. Despite its profile, the seat doesn’t punish the posterior on long rides.

The 450FX’s slim ergos allow the rider complete freedom to shift his or weight as necessary to maintain forward momentum.

The 450FX’s slim ergos allow the rider complete freedom to shift his or weight as necessary to maintain forward momentum.

“It’s really comfortable,” Garvin said. “It’s seating is such that you feel like you are really on top of the bike and can control it. I like the bar bend, which is a little lower than I am used to but fit this bike’s ergonomics perfectly. I’d have no trouble racing it in stock form.”

An 18-inch rear wheel is a virtual necessity for off-road racing, as the greater tire sidewall distance between the rim and the ground gives the tire more flex for better traction and better flat resistance. The FX features an 18-inch rear wheel, and both the front and rear wheels are shod with Dunlop’s excellent AT81 off-road tires, which deliver superb traction and feedback in a wide variety of off-road conditions.

Yamaha sweated many of the details on the 2016 YZ450FX. For instance, it is equipped with the aforementioned heavy-duty skid plate and rear disc sharkfin. That’s an improvement over the 2015 YZ250FX, which should have come from the factory with a skidplate, but didn’t. The FX also features radiators with a different fin pitch than the YZ to allow for better airflow through the radiators at low speeds.

Ambient temperatures hovered in the mid-60s for most of our ride, so we didn’t have to worry about the FX overheating in the technical sections of the test loop, but we know from experience that warm summer weather can quickly cause a 450s radiators to boil coolant when the going gets tight. At $69.95, Yamaha’s accessory Radiator Fan Kit is cheap insurance against cooking the FX’s motor in slow, hot or muddy conditions, and the FX is already pre-wired to accept the kit. Installation is a simple plug-and-play operation.

For $8,890, FX buyers can score themselves one heck of a versatile off-road motorcycle. If only it came with handguards and a larger fuel tank, it might be the bargain of the decade.

For $8,890, FX buyers can score themselves one heck of a versatile off-road motorcycle. If only it came with handguards and a larger fuel tank, it might be the bargain of the decade.

However, even though its $8,890 asking price is less than its Euro-bred competition, we would like to see the FX come from the factory fitted with the accessory GYTR handguards that we fitted to our stock machine. Yamaha sells them for $150. We also think that the FX deserves more fuel capacity in stock trim, and before you go thinking that this is a case of the YZ’s mid-mounted fuel tank layout prohibiting such a thing, don’t. IMS Products sells a 2.9-gallon tank for YZs, and Yamaha has already added the tank to its accessory catalog. For the FX to be truly off-road race ready, we say a larger tank should be included as part of the stock package.

Is that nitpicking? Maybe, but overall we really like Yamaha’s new open-class off-road racer. That should come as no surprise since we have been impressed with the progress that the company has made in developing the YZ450F platform during the 2015 and 2016 model years. And if we had to choose between the two models, we would probably go with the YZ450FX by virtue of its more adaptable transmission and electric start. For our money, the YZ450FX may just be the most versatile dirtbike on the planet today.

2016 Yamaha YZ450FX Specifications
MSRP $8,890
Engine Type Liquid-cooled DOHC 4-stroke Single; 4 titanium
valves
Displacement 449cc
Bore x Stroke 97.0mm x 60.8mm
Compression Ratio 12.5:1
Fuel Delivery Yamaha Fuel Injection (YFI) Keihin 44mm
Ignition Transistor Controlled Ignition
Transmission Wide-ratio constant-mesh 5-speed; multiplate wet clutch
Final Drive O-ring chain
Front Suspension Front KYB spring-type fork with speed sensitive damping; fully adjustable, 12.2-in. of wheel travel
Rear Suspension KYB single shock; full adjustable; 12.5-in. of wheel travel
Front Brake Hydraulic single disc brake, 270mm
Rear Brake Hydraulic single disc brake, 245mm
Front Tire Dunlop MX51 80/100-21
Rear Tire Dunlop MX51 120/90-18
Length 85.2 in.
Width 32.5 in.
Height 50.4 in.
Seat Height 38.0 in.
Wheelbase 57.7 in.
Rake (Caster Angle) n/a
Trail n/a
Ground Clearance 12.8 in.
Fuel Capacity 2.0 gal.
Wet Weight (claimed) 262 lbs.
Warranty 30 Day (Limited Factory Warranty)
Color Team Yamaha Blue/White
