2016 KTM XC 250 F

2016 KTM XC 250 F pictures, prices, information, and specifications.
Type
Off-Road
Insurance
Rating
Compare with the 2024 KTM RC 390 2024 KTM RC 390
Model Type
Off-Road
MSRP
$0
Dealers
Warranty
1
Insurance
Finance
Generic Type (Primary)
Off-Road
Manufacturer Country
Austria
Introduction Year
2012
Manufacturer Recommend Minimum Age
16
Parent Company
KTM
Display Name
XC 250 F
Photo Gallery
Standard
Year
2016
Make
KTM
Engine Type
Single-Cylinder
Cylinders
1
Engine Stroke
4-Stroke
Cooling
Liquid
Valves
4
Valves Per Cylinder
4
Valve Configuration
DOHC
Bore (mm/in)
78 / 3.07
Stroke (mm/in)
52.3 / 2.06
Displacement (cc/ci)
249.9 / 15.2
Compression Ratio
14.4:1
Starter
Electric / Kick
Fuel Requirements
Premium
Fuel Type
Gas
Carburetion Brand
Keihin
Fuel Injector
Yes
Fuel Injector Size (mm)
44
Carburetor
No
Carburetion Type
Fuel Injected
Transmission Type
Manual
Number Of Speeds
6
Overdrive
Yes
Primary Drive (Rear Wheel)
Chain
Gear Ratio (1/2/3/4/5/6)
2.46 / 1.88 / 1.5 / 1.22 / 1 / 0.85
Reverse
No
Final Drive Ratio
3.85
Wheels Composition
Aluminum
Tube / Tubeless
Tubed
Chromed
No
Tire Brand
Dunlop(R)
Front Tire Width
90
Front Tire Aspect Ratio
90
Front Tire Speed Rating
M
Front Wheel Diameter
21
Rear Tire Width
110
Rear Tire Aspect Ratio
100
Rear Tire Speed Rating
M
Rear Wheel Diameter
18
Front Tire (Full Spec)
Dunlop(R) GEOMAX AT81 90/90 R21 54M
Rear Tire (Full Spec)
Dunlop(R) GEOMAX AT81 110/100 R18 64M
Brake Brand Name
Brembo(R)
Front Brake Type
Hydraulic Disc
Front Brake Diameter (in/mm)
10.2 / 260
Rear Brake Type
Hydraulic Disc
Rear Brake Diameter (in/mm)
8.7 / 220
Front Suspension Type
Inverted Fork
Front Suspension Size (in/mm)
1.9 / 48
Front Travel (in/mm)
11.8 / 300
Front Adjustable Fork Pre-Load
Yes
Front Adjustable Rebound Damping
Yes
Front Central Suspension Strut
No
Front Suspension Brand Name
WP
Rear Suspension Type
Twin Sided Swing Arm
Rear Travel (in/mm)
12.5 / 317
Rear Adjustable Shock / Spring Pre-Load
Yes
Rear Adjustable Rebound Damping
Yes
Number Rear Shock Absorbers
1
Rear Suspension Brand Name
WP
Rear Suspension Material
Aluminum
Air Adjustable
No
Steering Control
Handlebar
Wheelbase (in/mm)
58.9 / 1495
Ground Clearance (in/mm)
14.8 / 375
Dry Weight (lbs/kg)
228.6 / 103.7
Fuel Capacity (gal/l)
2.5 / 9.5
Engine Displacement to Weight (cc)
1.09
Seat Type
One-Piece
Adjustable
No
Seat Material
Vinyl
Seat Location
Driver
Folding
No
Seat Height (in/mm)
39.1 / 992
Number Of Seats
1
Frame
Chromium Molybdenum
Body Material
Plastic
Hand Grips
Standard
Foot Peg Location
Driver
Adjustable
No
Drive Shaft Guard
No
Fork Guards
Yes
Saddle Bag Guard
No
Belt Guard
No
Hand Guards
Yes
Brush Guard
No
Heel Guards
Yes
Exhaust Guard
Yes
Light Guard
No
Side Cover
No
Fuel Tank Cover
No
Front Fender
Standard
Rear Fender
Standard
Top Crown
Standard
Stand Type
Kick
Handlebars
Standard
Handlebar Pads
Standard
Fuel Level Warning Type
Light
Warranty (Months/Condition)
1 / Limited
Battery Warranty (Months)
0
Adjustable Handlebars
Standard
Metallic
No
Decal Kit
Standard
