2016 KTM Adventure 1190 pictures, prices, information, and specifications.
Below is the information on the 2016 KTM Adventure 1190. If you would like to
get a quote on a new 2016 KTM Adventure 1190 use our
Build Your Own tool,
or Compare
this bike to other On-Off Road motorcycles.
Print this Page
Email to a Friend
Start New Search2016 KTM Adventure 1190 Specifications
Motorcycle Insurance:
| Identification | |
|---|---|
| Model Type | On-Off Road |
| BASE MSRP(US) | $TBA |
| Dealers | KTM Dealers |
| Warranty | 24 |
| Insurance | |
| Finance | |
| Engine: | |
| Engine Type | V Twin |
| Cylinders | 2 |
| Engine Stroke | 4-Stroke |
| Horsepower (bhp/kW) | 148 / 110 |
| Cooling | Liquid |
| Valves | 8 |
| Valves Per Cylinder | 4 |
| Valve Configuration | DOHC |
| Bore (mm/in) | 105 / 4.13 |
| Stroke (mm/in) | 69 / 2.72 |
| Displacement (cc/ci) | 1195 / 72.9 |
| Compression Ratio | 12.5:1 |
| Starter | Electric |
| Fuel Requirements | Premium |
| Fuel Type | Gas |
| Carburetion Brand | Keihin |
| Fuel Injector | Yes |
| Carburetor | No |
| Carburetion Type | Fuel Injected |
| Transmission: | |
| Transmission Type | Manual |
| Number Of Speeds | 6 |
| Primary Drive (Rear Wheel) | Chain |
| Gear Ratio (1/2/3/4/5/6) | 2.92 / 2.13 / 1.67 / 1.35 / 1.13 / 0.96 |
| Reverse | No |
| Final Drive Ratio | 2.47 |
| Wheels & Tires: | |
| Wheels Composition | Aluminum |
| Tube / Tubeless | Tubeless |
| Chromed | No |
| Tire Brand | Continental |
| Front Tire Width | 120 |
| Front Tire Aspect Ratio | 70 |
| Front Tire Speed Rating | W |
| Front Wheel Diameter | 19 |
| Rear Tire Width | 120 |
| Rear Tire Aspect Ratio | 60 |
| Rear Tire Speed Rating | W |
| Rear Wheel Diameter | 17 |
| Front Tire (Full Spec) | Continental ContiTrail Attack II 120/70 ZR19 60W |
| Rear Tire (Full Spec) | Continental ContiTrail Attack II 170/60 ZR17 72W |
| Brakes: | |
| Brake Brand Name | Brembo® |
| Front Brake Type | Dual Hydraulic Disc |
| Front Brake Diameter (in/mm) | 12.6 / 320 |
| Rear Brake Type | Hydraulic Disc |
| Rear Brake Diameter (in/mm) | 10.5 / 267 |
| Anti-Lock Brakes | Standard |
| Linked Brake System Front to Rear | Standard |
| Suspension: | |
| Front Suspension Type | Inverted Fork |
| Front Suspension Size (in/mm) | 1.9 / 48 |
| Front Travel (in/mm) | 7.5 / 190 |
| Front Adjustable Fork Pre-Load | Yes |
| Front Adjustable Rebound Damping | Yes |
| Front Central Suspension Strut | No |
| Front Suspension Brand Name | WP |
| Steering Damper | Yes |
| Rear Suspension Type | Twin Sided Swing Arm |
| Rear Travel (in/mm) | 7.5 / 190 |
| Rear Adjustable Shock / Spring Pre-Load | Yes |
| Rear Adjustable Rebound Damping | Yes |
| Number Rear Shock Absorbers | 1 |
| Rear Suspension Brand Name | WP |
| Rear Suspension Material | Aluminum |
| Air Adjustable | No |
| Steering: | |
| Steering Control | Handlebar |
| Technical Specifications: | |
| Wheelbase (in/mm) | 61.4 / 1560 |
| Ground Clearance (in/mm) | 8.7 / 220 |
| Dry Weight (lbs/kg) | 478 / 217 |
| Wet Weight (lbs/kg) | 518.1 / 235 |
| Payload Capacity (lbs/kgs) | 970 / 440 |
| Fuel Capacity (gal/l) | 6.1 / 23 |
| Fuel Capacity Reserve (gal/l) | 0.9 / 3.5 |
| Engine Displacement to Weight (cc) | 2.72 |
| Seats: | |
| Seat Type | Two-Piece |
| Adjustable | Yes |
| Seat Material | Vinyl |
| Seat Location | Driver and Passenger |
| Folding | No |
| Seat Height (in/mm) | 33.9 / 860 |
| Number Of Seats | 2 |
| Backrest Logo Plate | No |
| Grab Rail or Strap | Standard |
| Exterior: | |
| Frame | Chromium Molybdenum |
| Body Material | Plastic |
| Hand Grips | Standard |
| Foot Peg Location | Driver and Passenger |
| Adjustable | Yes |
| Chain Guard | Yes |
| Drive Shaft Guard | No |
| Fork Guards | Yes |
| Saddle Bag Guard | No |
| Belt Guard | No |
| Hand Guards | Yes |
| Brush Guard | No |
| Heel Guards | No |
| Exhaust Guard | Yes |
| Light Guard | No |
| Fuel Tank Cover | Yes |
| Front Fender | Standard |
| Rear Fender | Standard |
| Stand Type | Kick |
| Handlebars | Standard |
| Upper Fairing | Standard |
| Skid Plate | Standard |
| Instrumentation: | |
| Digital Instrumentation | Standard |
| Clock | Standard |
| Tachometer | Standard |
| Trip Odometer | Standard |
| Trip Computer | Standard |
| Lap Timer | Standard |
| Shift Light Type | Adjustable |
| Speedometer | Standard |
| Temperature Warning Type | Gauge |
| Fuel Level Warning Type | Gauge |
| Service Reminder | Standard |
| Pricing: | |
| Warranty (Months/Condition) | 24 / Limited |
| Basic Warranty (Miles) | 24000 |
| Identification: | |
| Generic Type (Primary) | On-Off Road |
| Manufacturer Country | Austria |
| Introduction Year | 2014 |
| Manufacturer Recommend Minimum Age | 16 |
| Parent Company | KTM |
| Display Name | 1190 Adventure |
| Mounts: | |
| Windshield Mounts | Standard |
| Paint & Finish: | |
| Metallic | No |
| Decal Kit | Standard |
| Glass: | |
| Rearview Mirrors | Standard |
| Windshield Lowers | No |
| Height Adjustable | Yes |
| Tinted | Yes |
| Height | Mid |
| Storage: | |
| Rear Rack | Standard |
| Lights: | |
| Halogen Headlight (s) | Standard |
| Headlight (s) | Standard |
| Type | Halogen |
| Convenience: | |
| Engine Immobilizer | Standard |
| Adjustable Handlebars | Standard |
| Adjustable Levers | Standard |
